Description
Vollrath FC-HCF-03208-AD Steam Tables & Food Wells – FC-HCF-03208-AD
Vollrath Model FC-HCF-03208-AD
From breakfast buffets to late-night dessert bars, this all-in-one insert keeps every course at its perfect serving temperature. Three independently-controlled wells switch instantly between hot, cold, and frozen modes—so you can plate steaming entrées, crisp salads, and ice-cold treats side-by-side from a single footprint.
Features
- True three-mode performance – each well operates in HOT, COLD, or FROZEN mode independently.
- Auto-Drain technology empties water automatically when switching from hot to cold/frozen.
- 4 ft (1.2 m) remote-mount electronic user interface with simple push/turn control.
- Accepts full-size or fractional pans up to 6 in (15.2 cm) deep; use adapter bars for fractional configurations.
- 18-gauge, 300-series stainless-steel top, wells, and interface built to withstand daily commercial abuse.
- Energy-smart design with foamed-in-place insulation and eco-friendly R290 refrigerant (low GWP).
- 2 in stepped cold-wall rim creates an NSF-compliant cold-air blanket over product.
- Self-contained ¼ HP refrigeration—no remote condensing unit required.
- Includes mounting clips for counters up to 3 in (7.6 cm) thick; 6 ft power cord with plug.
- Made in the USA and UL Listed / UL EPH Classified for peace of mind.
Specifications
| Well Count / Type | 3 independent wells (Hot / Cold / Frozen) |
|---|---|
| Pan Capacity | (3) full-size 12 × 20 in or fractional equivalents, up to 6 in deep |
| Controls | Touch/rotary electronic interface, 4 ft remote cable, last-setting memory |
| Drain | ¾ in integral drain per well (automatic) |
| Compressor | ¼ HP, self-contained |
| Refrigerant | R290 Hydrocarbon |
| Electrical | 120/208-240 V, 60 Hz, 1-phase, 1,875 W, 9.6 A |
| Plug | NEMA 14-20P, 6 ft (1.8 m) cord |
| Exterior Dimensions (W × D × H) | 65.7 × 26.0 × 24.4 in (166.9 × 66.0 × 62.0 cm) |
What our Experts Think
-
Three-mode flexibility: Each of the three wells can operate independently in hot, cold, or frozen mode — ideal for buffet lines, salad bars, or mixed-service menus.
-
Commercial-grade build: Constructed from 18‑gauge, 300‑series stainless steel with foamed-in-place insulation for durability and easy cleaning in heavy-use environments.
-
Energy-efficient refrigeration: Uses eco-friendly refrigerant and wrapped-coil cooling to maintain stable cold or frozen temperatures efficiently.
-
Practical pan compatibility: Accepts full-size or fractional pans up to 6″ deep, offering flexibility for a variety of dishes and portion configurations.
-
Easy installation and maintenance: Features an integral ¾″ drain, plug-in power cord, and mounting clips for quick setup and easy cleaning between service modes.
Q&A
*]:pointer-events-auto scroll-mt-[calc(var(–header-height)+min(200px,max(70px,20svh)))]“ dir=“auto“ data-turn-id=“request-WEB:1c25b482-16fd-4d66-b227-dbd51970fe69-43″ data-testid=“conversation-turn-86″ data-scroll-anchor=“true“ data-turn=“assistant“>
Q: What is the Vollrath FC-HCF-03208-AD?
A: It’s a modular 3-well drop-in food well unit that can operate in hot, cold, or frozen modes, designed for flush countertop installation in buffet or service lines.
Q: Why is this unit versatile?
A: Each well can be set independently to hot, cold, or frozen mode, allowing the same unit to hold hot entrées, chilled salads, or frozen desserts without needing separate equipment.
Q: What food containers does it accept?
A: Standard full-size or fractional food pans up to 6″ deep.
Q: How is it built?
A: Constructed from 18-gauge, 300-series stainless steel with foamed-in-place polyurethane insulation and refrigeration coils for efficient temperature control.
Q: Where is it best used?
A: Ideal for buffet lines, banquet service, cafeterias, salad bars, or any setting needing a flexible serving station that can handle hot, cold, or frozen items.
Maintenance Tips
-
Empty and rinse food wells after every use using warm water and a mild, food‑safe detergent to remove food residues.
-
Descale the unit periodically (especially in hard-water areas) using a manufacturer‑approved descaling solution — this helps preserve heating efficiency.
-
Wipe down exterior stainless‑steel surfaces with a soft cloth and mild, non‑abrasive cleaner to maintain appearance and hygiene.
-
Allow unit to cool and unplug before cleaning to avoid damage to heating elements or internal components.
-
Avoid steel wool, abrasive pads, or harsh chemicals, which can scratch or corrode surfaces.
-
Clean and inspect drain assemblies, faucets, and valves regularly to prevent blockages or leaks.
-
Check gaskets and seals periodically to ensure proper sealing and maintain temperature/steam retention.
